What is a Wound Rotor Induction Motor?
A wound rotor induction motor (WRIM) is a unique type of three-phase induction motor, known for its superior startup capabilities compared to the more common squirrel cage induction motor. This advantage makes it ideal for heavy-duty applications that require high starting torque, such as cranes, hoists, elevators, mills, and machines with large flywheels like punch presses and shears.
In this guide, we’ll explore the working principles of wound rotor induction motors, their key components, and the advantages and drawbacks that come with using them.
Understanding the Structure
A wound rotor induction motor has a specially designed rotor featuring three-phase wound coils. These coils are installed into a laminated core, similar to the stator winding found in other three-phase induction motors. The rotor windings are connected to three slip rings, each with a carbon brush that provides continuity to an external control circuit.
This unique setup allows the rotor to connect to a rheostat (a variable three-phase resistor), enabling the control of resistance across the rotor windings. This resistance can be adjusted to influence the motor’s starting torque and speed, providing a significant advantage in applications that require controlled startup and variable speed performance.
How Does it Work?
The operation of a wound rotor induction motor can be broken down into four key steps which I have outlined below.
- Starting with Full Line Voltage: The motor typically starts with full line voltage applied to the stator terminals. Resistance in the rotor circuit, provided by a star-connected rheostat, helps control the starting current and torque.
- Adjusting Rotor Resistance: As the motor speeds up, the resistance is gradually reduced. This reduction in resistance decreases the current in the rotor, while the starting torque is increased due to an improved power factor. The adjustable resistance allows the motor to achieve a high starting torque with a lower initial current draw.
- Speed Control via Resistance: During operation, additional resistance can be applied to control the motor speed. When resistance is added, the rotor current and motor speed decrease, while the induced voltage in the rotor windings increases. This relationship allows the motor to produce the necessary torque at a reduced speed, providing smoother acceleration and controlled performance for high-inertia loads.
- Transition to Squirrel Cage Mode: Once the motor reaches full operating speed, the resistance can be fully removed, allowing the wound rotor induction motor to function similarly to a standard squirrel cage motor.
Advantages & Disadvantages
Advantages
The unique construction of wound rotor induction motors offers several benefits, particularly for industrial applications:
- High Starting Torque: The ability to adjust resistance makes WRIMs ideal for applications that demand high starting torque, such as heavy lifting and machinery with large inertia.
- Speed Control: By adjusting rotor resistance, WRIMs offer variable speed control without requiring additional electronic controls, making them suitable for processes where speed variation is critical.
- Smooth Startup: Unlike squirrel cage motors, WRIMs allow for a smoother, controlled startup with lower initial current draw, reducing strain on the power system and the motor itself.
Disadvantages
Despite their advantages, wound rotor induction motors have some downsides that limit their modern-day use:
- Higher Maintenance: The slip rings and brushes in WRIMs require regular maintenance, increasing the upkeep costs compared to squirrel cage motors.
- Declining Relevance: With the advent of variable frequency drives (VFDs), which allow standard induction motors to achieve variable speed control, the need for WRIMs has decreased. VFDs now dominate industrial applications, offering efficient speed and torque control for traditional squirrel cage induction motors.
Wound Rotor Induction Motors vs. Variable Frequency Drives
Historically, wound rotor induction motors were the preferred choice for applications requiring variable speed control. However, as VFDs became widely available, the need for WRIMs declined. VFDs allow for precise speed and torque control without the need for additional motor components, such as slip rings and brushes, simplifying maintenance and reducing costs.
Final Thoughts
Wound rotor induction motors remain a valuable option in specific industrial applications, particularly where high starting torque and smooth speed control are required. However, their usage is gradually declining as VFDs continue to dominate the industry. If you are looking for a motor solution for high-inertia loads or specialized variable speed applications, a wound rotor induction motor could still be the ideal choice. However, for most modern installations, a VFD-controlled squirrel cage induction motor is likely to be more efficient and cost-effective.
